PRODUCT DESCRIPTION
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
RUBBER PIPE:Oil resistant synthetic rubber
rubber hose Reinforcement:One steel wire braided layer
rubber hose Cover:Oil, abrasion and weather resistant synthetic rubber. MSHA approved
rubber hose Temperature Range:-40° to 100°C (-40° to 212°F), petroleum base fluids intermittent to 125°C (257°F).
rubber hose Application:For medium pressure hydraulic oil lines, return lines, grease lines, water lines and power steering hoses.
|
DN |
Hose I.D |
Wire O.D |
Hose O.D |
Working Pressure |
Burst Pressure |
Minimum Bend Radius |
Weight |
Length | |||
|
inch |
mm |
mm |
mm |
MPa |
psi |
MPa |
psi |
mm |
kg/m |
metres | |
|
5 |
3/16 |
4.8 |
9.5 |
11.8 |
25.0 |
3630 |
100.0 |
14280 |
89 |
0.19 |
50/100 |
|
6 |
1/4 |
6.4 |
11.1 |
13.4 |
22.5 |
3270 |
90.0 |
12840 |
102 |
0.21 |
50/100 |
|
8 |
5/16 |
7.9 |
12.7 |
15.0 |
21.5 |
3120 |
85.0 |
12280 |
114 |
0.24 |
50/100 |
|
10 |
3/8 |
9.5 |
15.1 |
17.4 |
18.0 |
2615 |
72.0 |
10280 |
127 |
0.33 |
50/100 |
|
13 |
1/2 |
12.7 |
18.3 |
20.6 |
16.0 |
2320 |
64.0 |
9180 |
178 |
0.41 |
50/100 |
|
16 |
5/8 |
15.9 |
21.4 |
23.7 |
13.0 |
1890 |
52.0 |
7420 |
203 |
0.45 |
50/100 |
|
19 |
3/4 |
19.0 |
25.4 |
27.7 |
10.5 |
1530 |
42.0 |
6000 |
241 |
0.58 |
50/100 |
|
25 |
1 |
25.4 |
33.3 |
35.6 |
8.8 |
1280 |
35.0 |
5020 |
305 |
0.88 |
50 |
|
32 |
1 1/4 |
31.8 |
40.5 |
43.5 |
6.3 |
920 |
25.0 |
3600 |
419 |
1.23 |
20/40 |
|
38 |
1 1/2 |
38.1 |
46.8 |
50.6 |
5.0 |
730 |
20.0 |
2860 |
508 |
1.51 |
20/40 |
|
51 |
2 |
50.8 |
60.2 |
64.0 |
4.0 |
580 |
16.0 |
2280 |
635 |
1.97 |
20/40 |
Hydraulic Rubber Hose (SAE 100R2AT, DIN EN 853-2SN)
RUBBER PIPE:Oil resistant synthetic rubber
rubber hose Reinforcement:Two steel wire braided layer
rubber hose Cover:Oil, abrasion and weather resistant synthetic rubber. MSHA approved
rubber hose Temperature Range:-40° to 100°C (-40° to 212°F), petroleum base fluids intermittent to 125°C (257°F).
rubber hose Application:For medium pressure hydraulic oil lines, return lines, grease lines, water lines and power steering hoses.
|
|
Hose I.D |
Wire O.D |
Hose O.D |
Working Pressure |
Burst Pressure |
Minimum Bend Radius |
Weight |
Length | |||
|
inch |
mm |
mm |
mm |
MPa |
psi |
MPa |
psi |
mm |
kg/m |
metres | |
|
5 |
3/16 |
4.8 |
11.1 |
14.1 |
41.4 |
6000 |
160 |
23720 |
89 |
0.32 |
50/100 |
|
6 |
1/4 |
6.4 |
12.7 |
15.7 |
40 |
5800 |
160 |
22840 |
102 |
0.36 |
50/100 |
|
8 |
5/16 |
7.9 |
14.3 |
17.3 |
36 |
5250 |
140 |
20000 |
114 |
0.45 |
50/100 |
|
10 |
3/8 |
9.5 |
16.7 |
19.7 |
33.1 |
4800 |
132 |
18840 |
127 |
0.54 |
50/100 |
|
13 |
1/2 |
12.7 |
19.8 |
23.1 |
27.6 |
4000 |
110 |
15720 |
178 |
0.68 |
50/100 |
|
16 |
5/8 |
15.9 |
23 |
26.3 |
25 |
3630 |
100 |
14280 |
203 |
0.8 |
50/100 |
|
19 |
3/4 |
19.0 |
27 |
30.2 |
21.5 |
3120 |
85 |
12280 |
241 |
0.94 |
50/100 |
|
25 |
1 |
25.4 |
34.9 |
38.9 |
16.5 |
2400 |
65 |
9420 |
305 |
1.35 |
50 |
|
32 |
1 1/4 |
31.8 |
44.5 |
49.6 |
12.5 |
1820 |
50 |
7140 |
419 |
2.15 |
20 / 40 |
|
38 |
1 1/2 |
38.1 |
50.8 |
56.0 |
9 |
1310 |
36 |
5140 |
508 |
2.65 |
20/ 40 |
|
51 |
2 |
50.8 |
63.5 |
68.6 |
8 |
1160 |
32 |
4560 |
635 |
3.42 |
20 /40 |
HYDRAULIC HOSE DIN EN856 4SH
CONTINUOUS SERVICE TEMPERATURE RANGE: -40°F / +212°F; -40°C / +100°C
TUBE: OIL RESISTANT SYNTHETIC RUBBER
REINFORCEMENT: FOUR HIGH TENSILE STEEL SPIRALS
COVER: ENVIRONMENT RESISTANT SYNTHETIC RUBBER
APPLICABLE SPECS.: EN 856 4SH - ISO 3862-1 4SH
|
DN |
Hose I.D |
Wire O.D |
Hose O.D |
Working Pressure |
Burst Pressure |
Minimum Bend Radius |
Weight | |||
|
inch |
mm |
mm |
mm |
MPa |
psi |
MPa |
psi |
mm |
kg/m | |
|
19 |
3/4 |
19 |
29.2 |
33 |
42 |
6090 |
168 |
24360 |
280 |
1.61 |
|
25 |
1 |
25.4 |
36 |
39.9 |
38 |
5510 |
152 |
22040 |
340 |
2 |
|
32 |
1-1/4 |
31.8 |
42.9 |
47.1 |
32.5 |
4710 |
130 |
19850 |
460 |
2.64 |
|
38 |
1-1/2 |
38.1 |
49.8 |
55.1 |
29 |
4205 |
116 |
16820 |
560 |
3.36 |
|
51 |
2 |
50.8 |
64.2 |
69.7 |
25 |
3625 |
100 |
14500 |
700 |
4.98 |
HYDRAULIC HOSE DIN EN856 4SP
CONTINUOUS SERVICE TEMPERATURE RANGE: -40°F / +212°F; -40°C / +100°C
TUBE: OIL RESISTANT SYNTHETIC RUBBER
REINFORCEMENT: FOUR HIGH TENSILE STEEL SPIRALS
COVER: ENVIRONMENT RESISTANT SYNTHETIC RUBBER
APPLICABLE SPECS: EN 856 4SP - ISO 3862-1 4SP
RUBBER HOSE PIPE DIN EN 856 4SP
|
DN |
Hose I.D |
Wire O.D |
Hose O.D |
Working Pressure |
Burst Pressure |
Minimum Bend Radius |
Weight | |||
|
inch |
mm |
mm |
mm |
MPa |
psi |
MPa |
psi |
mm |
kg/m | |
|
10 |
3/8 |
9.5 |
17.5 |
21.4 |
45.0 |
6500 |
180.0 |
26000 |
180 |
0.78 |
|
13 |
1/2 |
12.7 |
20.2 |
24.6 |
41.5 |
6000 |
166.0 |
24000 |
230 |
0.93 |
|
16 |
5/8 |
15.9 |
23.8 |
28.2 |
35.0 |
5000 |
140.0 |
20000 |
250 |
1.17 |
|
19 |
3/4 |
19.0 |
28.2 |
32.2 |
35.0 |
5000 |
140.0 |
20000 |
300 |
1.48 |
|
25 |
1 |
25.4 |
35.5 |
39.7 |
28.0 |
4000 |
112.0 |
16000 |
340 |
2.02 |
|
32 |
1-1/4 |
31.8 |
46.0 |
50.8 |
21.0 |
3000 |
84.0 |
12000 |
460 |
3.05 |
|
38 |
1-1/2 |
38.1 |
52.4 |
57.2 |
18.5 |
2700 |
74.0 |
10800 |
560 |
3.52 |
|
51 |
2 |
50.8 |
65.3 |
69.8 |
16.5 |
2400 |
66.0 |
9600 |
660 |
5.20 |
